Hidden dangers during commissioning

Article#: 00099

Date: 2024-10-01

Author: Radim

Commissioning is an essential phase in any automation project. It's the point where theory meets reality, and systems come to life for the first time. However, it is also one of the most dangerous phases for engineers, technicians, and operators. As an automation engineer, I've seen first-hand how quickly things can go wrong during commissioning. The reason is simple: nothing has been fully verified at this stage, and blindly trusting the system can lead to catastrophic consequences.

Why is commissioning so risky?

1. Unverified code and logic: Before commissioning, the control logic has often not yet been tested in the real environment. Errors, overlooked or unconsidered situations can lead to unexpected behaviors. Motors and pneumatic actuators can start without warning, safety devices may not work and critical processes may fail.

2. Uncalibrated sensors and actuators: At the start of commissioning, the inputs and outputs of the system (such as sensors and actuators) are often uncalibrated. This can lead to inaccurate data or incorrect actions, creating dangerous situations like overpressure, overheating, or even mechanical failure.

3. Communication failures: Automation systems rely heavily on communication between different devices, controllers, and software systems. Early in commissioning, these communication lines may not be fully established, causing misinterpretation of commands or data, which can trigger unintended actions.

4. Inaccurate system models: Simulations and preliminary tests can only represent part of reality. The real system may behave differently due to unforeseen environmental factors, hardware variability, or interaction between subsystems.

5. Wiring errors: Incorrect wiring is a common hazard during the early stages of commissioning. Wires may be crossed, mislabeled, or improperly connected, leading to short circuits, power surges, or unintentional energizing of equipment. It's crucial to measure every wire and conductive part of the machine to ensure it is safe. Even when the wiring looks correct, measuring voltage, grounding, and continuity before powering up can prevent electric shocks or machine damage.

6. Human error: Misconfigured parameters, forgotten settings, incorrect wiring, carelessness, negligence, misinformation or trying to speed up the work can cause serious accidents.


Key safety practices for commissioning:

1. Assume nothing works: Start with the mindset that nothing is verified. Treat every system, device, wire, and signal as if it could fail or behave unpredictably.

2. Progress systematically in small steps: Break down commissioning tasks into small, controlled steps. Test each component or subsystem independently before integrating it into the larger system.

3. Measure before powering on: Always use a multimeter or other testing equipment to check the voltage, grounding, and continuity of wires and conductive parts before powering up the system.

4. Always have emergency stops: Ensure that physical and software-based emergency stops are functional and accessible. In dangerous situations, being able to quickly halt the system can save lives and equipment.

5. Use temporary safety measures: Before permanent safety mechanisms are in place, implement temporary barriers, interlocks, or guards to reduce risk.

6. Involve the whole team: Ensure that all stakeholders, including safety officers, operators, and maintenance staff, are aware of the dangers and the stage of commissioning. Clear communication can prevent accidents.

Commissioning can be one of the most dangerous phases in automation, but with proper planning, caution, and respect for the risks, it can be conducted safely. Always approach commissioning with the assumption that nothing works as expected until it has been thoroughly tested and verified.

© Radim-Automation, 2020–2025. All rights reserved.
Sharing of this article is permitted with proper attribution (link to the original page).

Related previous articles:

• Dedicated employees
• Code formatting
• Maintain order in the program code
• Keep the documentation up to date throughout the project
• PLC network diagram
• Diagnostic tools
• Event logger as the very first function implemented in the program
• It doesn't work without sensors
• Talk to operators
• Safety relays versus safety PLC
• Hardware concept
• Think critically!
• Design machines with a focus on user's abilities and needs
• Project leader
• Why do automation projects fail?
• Who will operate?
• Functional and intuitive HMI
• Write and accept only readable code!
• Appoint a representative!
• Are the people planned for this task really available?
• Write down your best practices and processes!
• HMI and PLC applications should grow together
• Do you really want to start with this?
• I can see what you can not see
• More than just start and stop
• Safety first!
• Do the right things and do them right!
• Define test scenarios and test cases continuously!
• Don't make it worse!
• Write a project diary!
• Keep the answers to the question "Why"
• Everything is difficult until it becomes easy
• Introduce the terminology and standardize it!
• Industrial evolution - Listen to your customers and follow new trends!
• Stay alert!
• Have an expert on hand!
• Ask questions!
• Assign tasks efficiently!
• Communication skills are extremely important
• Don't replace employees in the middle of the project!
• Develop a sense of responsibility!
• Recruit and retain the best employees!
• Get the things done with a small, motivated team!
• Focus on target!
• Think on paper!
• Multitasking is harmful
• Avoid overly optimistic estimates!
• 9 women can't make a baby in a month
• Don't hide any problem!
• Check the result!
• Keep it simple!
• Don't leave a work package half-finished!
• Choose the right tool!
• Good communication is important
• Development is evolution
• Don't neglect and don't skip any step!
• Transparency and reliability

Comment#: 00001

Date: 2024-10-01

User: Radim

If possible, gain experience with sensors and actuators during the programming and development phase, i.e. before commissioning. In this way, you will know how the device behaves, which states it can assume under different conditions and how to control it. The complete consideration of all possible states that you have encountered in practice ensures additional safety during commissioning.

Comment#: 00002

Date: 2024-10-01

User: Radim

Do not carry out any quick actions under power or without activating the safety measures! It is not worth saving a few minutes at the expense of risk.

Comment#: 00003

Date: 2024-10-01

User: Radim

Watch out for changes to the settings that could be made by another person or that could be caused by switching the device off and on. Always check the settings carefully!

Comment#: 00004

Date: 2024-10-04

User: Radim

Drive systems may perform unexpected movements because of incorrect wiring, incorrect settings, incorrect data or other errors!

Comment#: 00005

Date: 2024-10-04

User: Radim

Failure to follow these instructions can result in death, serious injury, or equipment damage.
