HMI - light versus dark design
Article#: 00111
Date: 2025-09-09
Author: Radim
The choice between dark and light design for HMI visualizations is not just a question of appearance.
Both approaches have their advantages and disadvantages, which become apparent depending on the operating environment in which the HMI is used.
Light design (light background, dark text and graphics):
- Very good readability in well-lit environments (e.g., day shift, production hall with sufficient lighting).
- High contrast makes it easier to recognize details and fine lines.
- Dirt (dust, fingerprints, stains) is less noticeable on a light background; legibility only deteriorates if the surface is heavily soiled.
- Disadvantage: In dark environments, the screen can be dazzling and cause eye strain.
Dark design (dark background, light text and graphics - also known as night mode):
- Practical in low light conditions: reduces glare and eye fatigue.
- Can reduce power consumption on OLED/AMOLED displays.
- Disadvantage: Dust, scratches, and grease are more visible on dark backgrounds. They can impair the perceived contrast and legibility of thin elements.
- Disadvantage: More limited selection of clearly recognizable colors for text and curves. Risk of reduced legibility of fine details.
If lighting conditions vary significantly, provide the option to switch between light and dark modes, either manually or automatically.
This ensures sufficient contrast at all times and minimizes glare in dark environments.
However, color consistency must be guaranteed in both modes.
Inconsistent color schemes can have serious consequences: slower or incorrect reactions by the operator, or even production downtime.
Always consider contrasts when creating your design.
Consider dust, smudges and scratches, not just a clean surface.
Test readability with real users in real operating environments (different shifts, lighting conditions, glare, and soiled screens).
© Radim-Automation, 2020–2026. All rights reserved.
Sharing of this article is permitted with proper attribution (link to the original page).
Related previous articles:
- What makes an HMI intuitive?
- HMI - colors in the visualization
- HMI – Don't hide anything
- HMI - back and forward navigation buttons
- HMI navigation
- HMI layout design
- HMI layout and correct display size
- Choosing an HMI display
- HMI is not a web page
- HMI - Don't overdo it with complex design
- HMI - Have a consistent style
- High Performance HMI
- Graphic designer
- Talk to operators
- Clear signals
- Design considerations for effective HMIS
- Are there also any disadvantages?
- Think critically!
- Design machines with a focus on user's abilities and needs
- Learn from your journey!
- Project leader
- Why do automation projects fail?
- Collect all the requirements and sort them!
- Who will operate?
- Functional and intuitive HMI
- Use a usefull styleguide!
- HMI and PLC applications should grow together
- More than just start and stop
- Safety first!
- Define test scenarios and test cases continuously!
- Don't make it worse!
- Keep the answers to the question "Why"
- Introduce the terminology and standardize it!
- Realize every good idea ASAP!
- Industrial evolution - Listen to your customers and follow new trends!
- What does the customer need?
- Focus on target!
- Check the result!
- Keep it simple!
- Choose the right tool!
- Transparency and reliability
Comment#: 00001
Date: 2025-09-11
User: Radim
Dark design is becoming increasingly popular, mainly because it looks modern and attractive. However, it also has its drawbacks, as mentioned in the article above. Some of them appear over time – for example, scratches and dirt are more visible and disturbing on dark backgrounds.
If we decide to use a dark design, it is also important to set the display brightness correctly: high enough to ensure readability in strong ambient light, and dimmed in dark environments so the screen does not cause glare.
